Some of our Hawle products are now available to download as BIM data on the website for free. You can download our BIM data in the desired format and integrate it into your CAD planning program.

To be able to use our CAD/BIM data, you must register on our Hawle portal. You will then receive access to the BIM data. You can recognise these by the cube icon, which is displayed under the product attributes.

More than 120 file formats in 2D or 3D are available. The CAD/BIM data are already deposited in all languages on the following products:

Water Plant construction

4000, 4150, 7160, 8500, 8510, 8520, 8530, 8540, 8550, 7800, 7100, 7110, 7130, 7150, 8000, 8110, 8200, 1500, 9970, 9940, 9941, 9942, 9943, 2001, 2002, 2011, 1090, 9870, 9870, 2280. 3100, 3101, 3102, 3600, 4017, 4019, 8100, 9967

Water Pipework construction

4020, 4027, 4028, 4320, 4321, 4330, 5412, 5413, 5477, 5330, 4522, 2521, 2523, 2701, 2801, 3121, 3123, 3131, 3521, 3711, 4040, 4045, 4110, 4280, 4212, 4251, 4252, 4253, 4350, 4364, 4370, 4381, 4480, 4500, 4510, 4520, 4572, 4576, 4582, 4586, 5211, 5252, 5310, 5346, 5350, 5360, 5370, 5372, 5380, 5400, 5410, 5411, 5420, 5440, 5470, 6160, 6161, 6162, 6180, 6190, 6301, 6302, 6381, 6450, 6451, 6511, 6512, 6514, 6850, 6852, 6856, 7200, 7205, 7220, 7225, 7240, 7245, 7260, 7320, 8060, 8070, 9100, 9110, 9630

The BIM catalogue will be continuously expanded for you with further Hawle products in the next few years.

If you have any questions, please do not hesitate to contact our application technology department.
